T-650D
Өсгөгч
650W дижитал холигч өсгөгч
- Гаралтын чадал
- 650W
- SNR (AUX1, 2)
- 80dB
PA чадал өсгөгч
Загварууд
T-650DTB
Өсгөгч
MP3/Tuner/Bluetooth-тэй 650W холигч өсгөгч
- RMS чадал
- 650W
- SNR (AUX1,2)
- 80dB
T-4240UC
Өсгөгч
4×240W матриц дижитал холигч өсгөгч
- Гаралтын чадал
- 4×240W
- Phantom тэжээл
- 48V
T-651
PA чадал өсгөгч
UC цувралын дууны хяналтын самбар
- Тэжээл
- DC 24V
- Самбарын хэмжээ
- 86mm
T-160DS
Өсгөгч
1 сувгийн 60W Class-D өсгөгч
- Нэрлэсэн чадал
- 60W
- Дохио/шуугианы харьцаа
- ≥85dB
T-61000D
Өсгөгч
1000W нэг сувгийн дижитал өсгөгч
- Нэрлэсэн чадал
- 1000W
- Дохио/шуугианы харьцаа
- >90dB
T-2120DS
Өсгөгч
2 × 120W, 2 сувгийн Class-D өсгөгч
- Нэрлэсэн чадал
- 2 × 120W
- Дохио/шуугианы харьцаа
- ≥85dB
T-4120DS
Өсгөгч
4 × 120W, 4 сувгийн Class-D өсгөгч
- Нэрлэсэн чадал
- 4 × 120W
- Дохио/шуугианы харьцаа
- ≥85dB
Харьцуулсан үзүүлэлт
| Загвар | |||
|---|---|---|---|
| Input Sensitivity and Impedance | MIC1, 2, 3, 4 Input:5mV/600Ω Unbalanced 6.3 connector; AUX1, 2 Input: 350mV/10KΩ Unbalanced RCA connector; EMC Input: 775mV/10KΩ Unbalanced 6.3 connector | MIC1,2,3,4 input: 5mV / 600Ω unbalanced 6.3 connection terminal; AUX1,2 input: 350mV / 10KΩ unbalanced RCA connection terminal; EMC input: 775mv / 10KΩ unbalanced 6.3 connection terminal | INPUT1-4: 5mV-350MV±40MV/600Ω; LINE1-2: 350mV±40MV/10KΩ unbalanced RCA connector; EMC: 775mV/10KΩ unbalanced European connector |
| Output Sensitivity and Source Impedance | MIX OUT:1000mV/470Ω Unbalanced RCA connector | MIX OUT: 1000mV / 470Ω unbalanced RCA connection terminal | CH1-2: 1000mV/470Ω unbalanced RCA connector |
| Tone | Bass: ±10dB at 100Hz; Treble: ±10dB at 10KHz | Bass: ± 10dB at 100Hz; Treble: ± 10dB at 10KHz | Bass: ±10dB at 100Hz; Treble: ±10dB at 10KHz |
| Frequency Response | 80Hz~16kHz(+1dB,-3dB) | 80Hz ~18KHz (+ 1dB, -3dB) | 80~16KHz(+1dB,-3dB) |
| Signal-to-Noise Ratio (SNR) | MIC1, 2, 3: 66dB; AUX1, 2: 80dB | MIC1,2,3: 66dB; AUX1,2: 80dB | INPUT1-4:66dB; LINE1-2:80dB |
| Total Harmonic Distortion (THD) | Less than 0.5%(at 1KHz, 1/3 Rated Power) | < 0.5% (at 1KHz, 1/3 rated power) | < 0.5% (at 1KHz, 1/3 rated power) |
| Protection | Short circuit, overload and overheat | Overheat protection, overcurrent protection, short circuit protection | High temperature, overload, short circuit |
| Power Supply | ~220-240V /50Hz (V series has built-in DC24V power input) | ~ 220 -240V/ 50Hz | 230V/50Hz |
| Power Consumption | 850W | 850W | 1200W |
| Dimensions | 484×300×44mm | 484 ×300 × 44mm | 484x395x88mm |
| Weight | 4.2kg | 4.3kg | 7.6kg |
| Output Terminal | 4-16Ω, 100V | — | 4-16Ω, 100V |
| Output Power | 650W | — | 4*240W |
| Mute Function | EMC>MIC1>MIC2, MIC3, AUX1, AUX2 | MIC 1 is prior to MIC2-4, AUX1-2 audio input; EMC is prior to all audio inputs | — |
| Channel Crosstalk Attenuation | ≥50dB | ≥50dB | — |
| Heat Dissipation | The fan starts work when powered on. Winds flank in and out from the back, can lead to strong cooling effect. with infinitely variable speed. | Side-in and rear-out forced fan cooling; fan starts automatically when the device is turned on; infinitely variable speed | — |
| Output | — | 4-16Ω, 100V | — |
| RMS Power | — | 650W | — |
| Phantom Power | — | — | 48V (±2V) |
| Cooling | — | — | Fan forced cooling |
